T20 hand-held control unit
The T20 hand-held pendant station offers maximum ergonomics in an extremely robust and ergonomic housing for manual teaching of the robot system. All gripping and holding positions enable comfortable and fatigue-free operation of the device. The T20 hand-held control unit is compatible with all robot systems that are controlled via the SmartController EX.
